Low Profile Simplex Fiber Optic Connector Adapter IP67 Compatible To Corning OptiTap

Name: Low Profile Simplex Fiber Optic Connector Adapter IP67 Compatible To Corning OptiTap
Brand: UNIFIBER-OEM
Price: 1 USD

Brand Name : UNIFIBER-OEM

Model Number : MINISC

Certification : ROHS

Place of Origin : CHINA

MOQ : 10pcs

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 10000PCS/DAY

Delivery Time : 3-5days

Packaging Details : PE bag

Insertion Loss : 0.25dB

Adapter : SC simplex male to female

Return Loss : APC>65dB

Waterproof : IP67

Compatiable : Corning Optitap SC

Application : FTTA

Contact Now

Outdoor waterproof Mini SC connector adapter IP67 compatible to Corning optiTap connectorsMini SC assemblies provide a robust and sealed connection solution for fiber to the home (FTTH) connectivity.like as H connector end incorporates an SC/APC type connection within a slim, sealed, threaded polymer housing allowing easy connection to either a multi port terminal or in-line extension receptecal.The mini SC/APC connectors mate to a standard adapter providing a common interface for FTTX applications

Features:

IP-67 water and dust protection
Factory terminated for high performance
-40ºC~85ºC operating temperature
445N (100 lbs) cable retention
Accepts 2.0mm to 7.0mm cable diameters
Low profile in-line receptacle available
No installation tools requires

Application

Provides superior weather resistance for FTTA and other outdoor applications.
Allows flexibility to use factory terminated assemblies or pre-terminated or field installed assemblies
Suitable for FTTA and outdoor temperature extremes Ensures functionality in harsh weather environments
Can be installs without special tooling
Threaded style coupling
Provides bend protection for installation and long term use

odel	SM MM
SC Connector Fiber Count	1 core
SC SX Adapter Mini SC compatible	PC, APC
Insertion Loss Standard type	less than 0.25dB
Insertion loss Elite type	Less than 0.2dB
Return Loss	PC >50dB, APC>60dB
Durability (500 matings)	less than 0.2dB
Pulling Force (N)	450N

Product Tags:

waterproof cable assembly

fiber optic connector assembly

Low Profile Simplex Fiber Optic Connector Adapter IP67 Compatible To Corning OptiTap Images
